Magnetic Separator
Magnetic Separator

Product introduction:The minerals are evenly sent to the upper part of the separation drum through the vibrating feeder. Then the rotating drum throws the non-magnetic materials away from the drum while the magnetic materials are attracted to the drum by the strong magnetic force. So the magnetic and non-magnetic materials are easily and accurately separated by the separation plate.

Technical Features
  • Widely Applicable
  • Environmental Protection
  • Easy To Maintain
  • Optional Discharge Method
  • Large Processing Capacity
  • ● Strong material adaptability, continuous production, easy to adjust the fineness of the milled product.

  • ● It has a good dust removal effect because the discharge port adopts a straight cylindrical design and is equipped with a draft device.

  • ● The simple structure is easy to maintain. The hollow shaft is made of cast steel making, so it easier to disassemble and replace the lining.

  • ● According to the material and the discharging method the overflow type dry ball mill or the grid type dry ball mill can be selected.

  • ● It retains the structure of the end cover of the ordinary mill with a large diameter inlet and outlet and large processing capacity.


Product Gallery

Performance parameter
Model
Drum Spec
(Dia *length)(mm)
Capacity(t/h)
Feeding
Size(mm)
Motor
Power(kw)
Water
Content
of Raw ore(%)
Rotation
Speed(r/min)
Magnetic
Intensity(mT)
Weight(t)
TNG-7518 750×1800 40-50 0-8 3 ≤3 34 250-800 1.98
TNG-7519 900×1800 45-55 0-8 4 ≤3 30 250-800 2.8
TNG-7520 1050×1800 100-120 0-8 5.5 ≤3 24.5 250-800 4
TNG-7521 1050×2100 125-145 0-8 5.5 ≤3 24.5 250-800 4.5
Model
Cylinder
D x L(mm))
Cylinder
speed(r/min)
Feed size(mm)
Ore conc
entration(%)
Working gap(mm) capacity power(kw) weight(kg)
Overall
dimension(mm)
Dry ore(t/h)
Slurry
powder(m³/h)
CTB612 600×1200 35 0-0.4 20-25 30-40 10-15 10-15 2.2 1200 2550x1300x1250
CTB618 600×1800 35 0-0.4 20-25 30-40 15-20 15-20 2.2 1500 3150x1300x1250
CTB712 750×1200 35 0-0.5 20-25 30-40 15-20 15-20 2.2 1830 2770x1780x1600
CTB718 750×1800 35 0-0.5 20-25 30-40 30-35 30-35 3 2045 3350x1780x1600
CTB918 900×1800 20 0-0.8 20-35 45-75 30-35 100-150 4 3500 3426x1886x1606
CTB924 900×2400 20 0-0.8 20-35 45-75 40-60 120-180 4 4000 3926x1886x1606
CTB1018 1050×1800 20 0-0.8 20-35 45-75 50-100 170-200 4 4095 3440x2220x1830
CTB1024 1050×2400 20 0-0.8 20-35 45-75 70-130 200-300 5.5 5071 4032x2220x1830
