The CSV132 Symons cone crusher has won the trust and praise of many customers for its excellent performance and efficient crushing capacity. This crusher is particularly suitable for crushing various ores and rocks with medium or higher hardness. It has the characteristics of reliable structure, high production efficiency and convenient adjustment. It can be widely used in metallurgy, construction, hydropower, transportation, chemical industry, building materials and other industries.
The working principle and product design characteristics of CSV 132 Symons Cone Crusher
Vanguard Machinery CSV132 Symons cone crusher compound cone crusher achieves efficient crushing through its unique structure and design. When the CSV series hydraulic cone crusher is working, the motor drives the pulley or coupling, and the drive shaft and the cone part make the eccentric shaft perform periodic swing motion under the axis line. After the material enters the crushing chamber from the feed inlet, it is crushed due to the mutual impact, extrusion, grinding and kneading of the eccentric shaft and the concave. After multiple extrusions, impacts and bends, the material crushed to the required particle size falls under its own gravity and is discharged from the bottom.
Vanguard Machinery CSV series hydraulic cone crusher adopts a special crushing frequency and eccentricity, which makes the fine-grained content in the crushed product higher, and the content of particles smaller than the closed edge discharge port can reach 80%, which improves the processing capacity of subsequent processes and reduces the overall energy consumption. In addition, the CSV series hydraulic cone crusher also has automatic control of overload protection and cavity clearing functions, thanks to its built-in safety cylinder design. This design eliminates the trouble of the original spring cone crusher needing to stop for manual discharge, greatly reducing the maintenance rate. At the same time, it adopts a hydraulic lubrication combined oil station design, which is not only small in size and simple in wiring but also improves the stability and reliability of the equipment.
